    Safety technology

    KeSafe

    Maximum safety for man and machine

    The KeSafe safety technology solution is available in combination with the compact control and drive system KeDrive for Motion. A safety CPU including optimized software ensures safe operation of machines and robots in accordance with current standards and directives.


    KeSafe’s functions range from simple logic operations and safe single-axis functions to enhanced safety functions for robot applications with up to 12 axes.

    For the simple and efficient creation of safety applications, a range of certified function modules are available which, as with a functional PLC, can be combined individually.


    KeSafe complies with the following norms:

    • Complete solution up to category 4, PLe according to EN ISO 13849-1 and SIL3 according to EN 62061 and EN 61508
    • Safe single-axis functions according to EN 61800-5-2 (KeSafe Motion)
    • Safe robotics modules according to EN ISO 10218 (KeSafe Robotics)
    Save space with KeSafe


    Maximum safety in the smallest of spaces

    Space-saving

    KeSafe guarantees the safe monitoring of the robot working areas, the speed at the TCP and freely definable robot points.

    This enables safe man-machine cooperation as well as space-saving cells with minimal footprint.

    Hardware and software perfectly matched

    KeSafe

    Used in the following systems


    KeMotion

    KeMotion

    The complete solution for the automation of robots and machines

    Read more

    KeControl FlexCore

    KeControl FlexCore

    The open control platform for individual control solutions

    Read more
