Safety and quality
under all conditions
The KEBA Testhouse – simulating environmental conditions to ensure your products withstand the extreme.
Environmental test at the KEBA Testhouse
Your specialized testing laboratory for environmental tests
Our environmental testing laboratory specializes in testing products under realistic and extreme environmental conditions. Using state-of-the-art testing technology, we simulate heat and cold, humidity, splash water, dust and other influencing factors to ensure the durability and longevity of your devices. This enables us to identify weak points at an early stage and support you in optimizing your products for worldwide use. Our experts accompany you from prototype to series release and ensure precise, standard-compliant testing.
The added value for you: increased reliability, minimized risk of failure in the field and the certainty that your products meet the defined requirements for harsh environmentalconditions.
-
Experience with impact : Our team of highly qualified test engineers and consultants shortens lead and throughput times. You also benefit from our high standards of precision and practical results
-
More than just compliance with standards: Our understanding of values goes beyond standardized testing - as a long-term partner, we support you in your project to optimize your product
-
Flexible & approachable: Personal and direct contact between the client and testing technician is important to us - this enables flexible scheduling, on-site modifications and clear and transparent processes
-
All-round support: From pre-compliance tests to support with the CE declaration - we are at your side
Standards and specializations
Extract of available test methods, test equipment, standards and specializations
| Test | Details | Test equipment |
|---|---|---|
| Splash water chamber (IP) EN 60529 | IPX3 - water spray at an angle of up to 60° IPX4 - splash water from any direction IPX5 - Water jet test from any direction IPX6 - test with strong water jets Test volume: hemisphere with 400 mm radius Weight load turntable: 50 kg | Spritzwasserkammer: SPK R600, iTS |
| Dust chamber (IP) | IP5X - Dustproof IP6X - Dust-tight Vacuum device: 25 mbar Test volume: 800 x 800 x 800 mm Side wall as bulkhead Weight load capacity of test grid: 100 kg / m² | Staubkammer: SK1000-10, iTS |
| Weathering tester Outdoor area ageing simulation of material samples DIN EN ISO 4892-2 | Xenon lamps with daylight filter Daylight-Q 300 to 800 nm Sample area: 450 x 720 mm Weight load capacity: max. 25 kg | Bewitterungstester: Q-SUN Xe-3-HSE, Q-Lab Bestrahlungsstärkesensoren UC20/TUV, Q-Lab Schwarzstandard Temperatursensor UC202/IBP, Q-Lab |
| Climate and temperature tests EN 60060-2-30 (damp heat, cyclic) EN 600620-2-78 (damp heat, steady state) | Temperature range: up to -40°C to 180°C Temperature change rates: Heating: up to 5.5°C/min Cooling: up to 5°C/min Test chamber dimensions: up to 1100 x 950 x 1475 mm W x H x D Test chamber volume: max. 1,540 l, 1.5 m³ Max. Test item weight on test chamber floor: up to 150 kg (evenly distributed over the surface), 50 kg per insertion grid | Temperature oven: VT3 4034, Vötsch Climate chambers: HPP110, Memmert ClimeEvent C/340/0, Weiss MKF 1020 E5, Binder VCS 4150-5, Vötsch |
| Climate chamber EN 60060-2-30 (damp heat, cyclic) EN 600620-2-78 (damp heat, steady state) | Temperature range: -20°C to 70°C Relative humidity: up to 45% to 98% Temperature change rates: Heating: approx. 1.5°C/min Cooling: approx. 3°C/min Test room dimensions: 2.5 x max. 3.2 (2.3) x 3.7 m W x H x D Test room volume: 29,600 l, 29.6 m³ | Hauser climate chamber |
Environmental assessment process
Requirements analysis & test planning
Clarification of standards, specifications and operating conditions
Examination preparation
Preparation of the test specimens and integration into the test environment
Test execution
Product testing with continuous monitoring and data acquisition according to your specifications
Analysis of the results
Analysis of the results and identification of weak points as well as the creation of standard-compliant test reports
Feedback & Optimization
Feedback to the customer and support with product optimization
Services
At KEBA we support you with our experience in product testing for your application.
Pre-Compliance tests
Pre-compliance tests identify potential weaknesses at an early stage - for efficient product optimization during development, shorter test cycles and faster market entry.
Test reports
Our test reports provide clear and comprehensible results - as a reliable basis for your technical documentation, conformity assessment and product optimization.
Consulting
Our targeted consulting combines technical expertise with practical solutions - for efficient test processing and successful product qualification.
